research article

Ultrafast All-Polymer Electrically Tunable Silicone Lenses

Maffli, Luc
•
Rosset, Samuel
•
Ghilardi, Michele
Show more
2015
Advanced Functional Materials

Dielectric elastomer actuators (DEA) are smart lightweight flexible materials integrating actuation, sensing, and structural functions. The field of DEAs has been progressing rapidly, with actuation strains of over 300% reported, and many application concepts demonstrated. However many DEAs are slow, exhibit large viscoelastic drift, and have short lifetimes, due principally to the use of acrylic elastomer membranes and carbon grease electrodes applied by hand. Here a DEA-driven tunable lens, the world's fastest capable of holding a stable focal length, is presented. By using low-loss silicone elastomers rather than acrylics, a settling time shorter than 175 μs is obtained for a 20% change in focal length. The silicone-based lenses show a bandwidth 3 orders of magnitude higher compared to lenses of the same geometry fabricated from the acrylic elastomer. Stretchable electrodes, a carbon black and silicone composite, are precisely patterned by pad-printing and subsequently cross-linked, enabling strong adhesion to the elastomer and excellent resistance to abrasion. The lenses operate for over 400 million cycles without degradation, and show no change after more than two years of storage. This lens demonstrates the unmatched combination of strain, speed, and stability that DEAs can achieve, paving the way for complex fast soft machines.

  • Files
  • Details
  • Metrics
Loading...
Thumbnail Image
Name

AFM_lens_article_infoscience.pdf

Type

Postprint

Version

Accepted version

Access type

openaccess

Size

11.76 MB

Format

Adobe PDF

Checksum (MD5)

7f881cacce3e2d79c3af534424af4d80

Loading...
Thumbnail Image
Name

Maffli_AFM_2015.pdf

Type

Publisher's Version

Version

Published version

Access type

restricted

Size

3.77 MB

Format

Adobe PDF

Checksum (MD5)

5d4f2dd1fab13dd2f6abb383016df46d
