Design and Fabrication of Robot-Manufactured Joints for a Curved-Folded Thin-Shell Structure Made from CLT

The prototype presented in this chapter utilizes the technique of curved folding for the design of a thin-shell structure built from curved cross-laminated timber panels (CLT). The curved-folded geometry allows for a span of 13.5 m, at a shell thickness of only 77 mm. The construction requires curved line CLT joints, which are difficult to address with state-of-the-art jointing techniques for CLT. Inspired by traditional woodworking joinery, we have designed connections for the integrated attachment of curved CLT panels, utilizing digital geometry processing tools to combine the advantages of traditional joinery techniques with those of modern automation technology.


Editor(s):
McGee, Wes
Ponce de Leon, Monica
Published in:
Robotic Fabrication in Architecture, Art and Design 2014, 67-81
Year:
2014
Publisher:
Vienna / New York, Springer International Publishing
ISBN:
978-3-319-04662-4
Keywords:
Laboratories:




 Record created 2014-03-27, last modified 2018-01-28
